[Clamp] pipeline expansion joints “instead of flanges”
Shanghai Songjiang Group Manufacture Clamp pipeline expansion joints “instead of flanges” are used for pipeline vibration isolation, noise reduction and displacement compensation joints. It is a high elasticity, high air tightness, medium resistance and weather resistance pipe joint.
Clamp pipeline expansion joints are generally used in low-pressure pipeline systems such as oil return pipelines, drainage pipelines, and powder transportation system, pressure not higher than 1kg, diameter, length, thickness, material (high temperature, hydraulic pressure, food)
Can be customized, the general cycle is 15 days;
For example: wind power generation oil return pipe, food powder transportation;
Use clamp joints instead of flanges and anchor bolts. In application, the two pipes of the pipeline expansion joints of the clamp can be easily put on the pipeline to be connected, and the flexible rubber joint can be fixedly connected to the pipeline according to the clamped joint; and achieve the purpose of compensating for the offset caused by the expansion of the pipeline due to thermal expansion and contraction and the passage of water.
Compared with ordinary pipeline expansion joint, it has the following characteristics:
1. The clamp pipeline expansion joint saves flanges and anchor bolts and saves the expenditure of engineering projects.
2. The clamp pipeline expansion joint does not need the reverse side, which simplifies the manufacturing process of the pipeline expansion joint and saves the raw material.
3. The clamp pipeline expansion joint simplifies the installation and maintenance work and improves the work efficiency.
4. The clamp joint is made of stainless steel and has the characteristics of anti-corrosion. The pipe diameter is from DN50-400, and the working pressure level is from 0.25mpa-1.0mpa. According to the specific working conditions, different machinery and equipment should be used for installation. pipeline expansion joint It occupies a major part in the industrial pipeline and has great influence. Because of its own advantages and characteristics, it is favored by customers.
