[304] Stainless Steel Flanged Pipeline Expansion Joint DN150 “Lined with PTFE”

Single Sphere Pipeline Expansion Joint | 2022-05-18

[304] Stainless Steel Flanged Pipeline Expansion Joint DN150 “Lined with PTFE”

Shanghai Songjiang Group Introduce to you: [304] Stainless Steel Flanged Pipeline Expansion Joint DN150 “Lined with PTFE”information. Songjiang Group had equipped fully automatic production plant, manufacturer various of pipeline expansion joints products with 5 years warranty.

[304] Stainless Steel Flanged Pipeline Expansion Joint

Model: KXT-SS 304-PTFE
Pressure: PN16
Caliber: DN150
Length: 180mm
Axial compression: 18mm
Axial stretch: 10mm
Lateral displacement: 12mm
Deflection angle: 15°
Flange material: stainless steel 304 (support spectrometer detection.)
Rubber material: NBR/ EPDM
Lining material: PTFE
Applicable medium: strong acid and alkali
Manufacturer: Shanghai Songjiang Shock Absorber Group Co., Ltd.
Attached certificates: certificate of conformity, quality assurance certificate, test report, material certificate, TS pressure pipeline production license, etc.

[304] Stainless Steel Flanged Pipeline Expansion Joint is mainly used for pipeline to reduce vibration, reduce noise, good flexibility and easy to use. Single sphere expansion joint is also called single ball rubber soft joint, single ball soft joint, shock absorber, pipeline shock absorber, It is a kind of pipe joint with high elasticity, high air tightness, medium resistance and weather resistance. This product takes advantage of the elasticity, high air tightness, medium resistance, weather resistance and radiation resistance of rubber. It is made of high temperature mold vulcanization. The single ball rubber joint is made of fabric reinforced rubber parts and flat unions. It is the first kind of pipe joints with high elasticity, high air tightness, medium resistance and weather resistance.
