KXT Type PVC Flange EPDM Pipeline Expansion Joint DN100

Model: KXT-PVC-EPDM

Specifications: DN100

Pressure: PN16

Length: 150mm

Axial compression: 18mm

Axial stretch: 10mm

Lateral displacement: 12mm

Deflection angle: 15°

Inner layer rubber: EPDM rubber (all using Japan’s Mitsui 4045, the rubber content reaches about 46%, and there are qualification certificates such as third-party material reports, content testing reports, etc.)

Outer layer rubber: EPDM rubber (all using Japan’s Mitsui 4045, the rubber content reaches about 46%, and there are qualification certificates such as third-party material reports, content testing reports, etc.)

Skeleton layer: nylon cord

Booster ring: multi-strand steel wire

Flange: PVC

Applicable medium: sea water, weak acid and alkali

The Characteristics of EPDM pipeline expansion joint

The characteristics of EPDM pipeline expansion joint are the same as ordinary rubber joints. They have the characteristics of small size, light weight, good elasticity, good sealing, and easy installation, maintenance and replacement. During installation, axial, lateral and angular displacement can be generated, and it is not affected by pipeline failure and non-parallel flanges. When working, it can reduce the noise transmitted by the structure and has strong vibration absorption ability.

EPDM rubber has excellent weather resistance, ozone resistance, heat resistance, acid and alkali resistance, water vapor resistance, color stability, electrical properties, oil-extending properties and fluidity at room temperature. EPDM rubber has good compatibility and co-vulcanization with butyl rubber.

If the situation is special, EPDM pipeline expansion joint can also be used in ordinary water medium, but the material of EPDM pipeline expansion joint is higher than that of ordinary rubber joints. In terms of adapting to the environment, this rubber joint is resistant to temperature, acid and alkali. , The characteristics of corrosion resistance, in the corresponding pipeline equipment, can effectively prevent the erosion of corrosive media to the inner wall of the rubber joint, and effectively improve the service life of the equipment.
