KXT Type Pipeline Expansion Joint DN25-DN1200mm information:
Parameter of KXT Type Pipeline Expansion Joint
Specifications：DN25-1200mm
Length：95-260mm
Stretch：6-16mm
Compression：9-25mm
Displacement：9-22mm
Deflection：15-5 degree
Working Pressure：0.6Mpa、1.0Mpa、1.6Mpa、2.5Mpa
Product Certification：ISO9001-2008
KXT Type Pipeline Expansion Joint Features
Working temperature: -40 degrees to 80 degrees (also can process high temperature resistant rubber soft joints)
Inner/Outer Rubber : NR, NBR, EPDM, FKM, CR， PTFE Lining
Key frame: Nylon cord （Nylon 6）
Pressurized ring: multi-strand steel wire
Flanges: Q235, SS304, SS316, PVC, DN40-DN200(QT450)
Applicable medium: air, compressed air, drinking water, sewage, sea water, hot water, oil, acid and alkali, etc.
Natural rubber: NR ≤80 degrees High pressure resistance.
EPDM rubber: EPDM ≤120 degrees, high temperature resistance, acid and alkali resistance, corrosion resistance, seawater resistance.
Nitrile rubber: NBR ≤80 degrees, good oil resistance.
Fluorine rubber: FKM ≤120 degrees, high temperature resistance, oil resistance, strong acid resistance.
Note: Selecting different rubber raw materials has different functions.
The KXT Type Pipeline Expansion Joints main purpose and scope of application：
KXT Type Pipeline Expansion Joints are widely used in chemical, construction, water supply, drainage, petroleum, light and heavy industry, refrigeration, sanitation, plumbing, fire protection, electric power and other basic projects, especially suitable for pipelines with large vibration and frequent changes in cold and heat.
KXT Type Pipeline Expansion Joints Working principle and structural features：
This product mainly utilizes the good high elasticity, good sealing performance and thermal expansion and contraction of rubber, which reduces the vibration and noise of the pipeline, and compensates for the thermal expansion and contraction caused by temperature changes effect.
