[Patent Product] Carbon Steel Flange Pipeline Expansion Joint

Shanghai Songjiang Group introduces to you: [Patent Product] Carbon Steel Flange Pipeline Expansion Joint information, Songjiang Group provides new Carbon Steel Flange single sphere pipeline rubber bellows for many customers, the flange adopts a new design and has applied for the appearance Design patent, lighter construction, and more novel appearance.

Rubber joint industry TS pressure pipe production license enterprise, TS number: TS2731B90-2020

Carbon Steel Flange EPDM Pipeline Expansion Joint

Model: KXT-EPDM

Caliber: DN80

Pressure: 1.6Mpa

Length: 135mm

Axial compression: 12mm

Axial tension: 6mm

Lateral displacement: 10mm

Deviation angle: 15 degrees.

Rubber material: EPDM rubber (Mitsui 4045)

Flange material: carbon steel / ductile QT450 / stainless steel.

Flange standard: GB/T 9119-2000 (in addition to this flange standard, our factory can also support more flange standards, if you need to know other flange standards, please click: rubber joint flange standard)

Applicable media: weak acid and alkali, strong alkali, lime slurry, desulfurization, chemical plant sewage, high temperature below 120 degrees; (Note: strong acid and alkali, dilute sulfuric acid can not be used, to choose tetrafluororubber joint can be used.)

Advantages: shock absorption, noise reduction, protection of hydraulic equipment for long-term use, and reduced maintenance costs.

Warranty period: 12 months.

Manufacturer: Shanghai Songjiang Shock Absorber Group Co., Ltd.

Qualification Certificate: Qualification Certificate, Quality Assurance Certificate, Inspection Report, TS Pressure Pipeline Production License of Rubber Joint Industry, National Type Test Report, Third Party Performance Test Report, Content Component Test Report.
