[PVC Flange] Double Sphere Pipeline Expansion Joint

Double Sphere Pipeline Expansion Joint | 2022-05-17

Overview of [PVC Flange] Double Sphere Pipeline Expansion Joint

PVC flange Double Sphere Pipeline Expansion Joint is mainly used for pipeline to reduce vibration, reduce noise, good flexibility and easy to use. Double Sphere Pipeline Expansion Joint, also known as Double Sphere Pipeline Expansion Joint, Double Sphere soft joint, shock absorber, pipeline shock absorber, shock absorber, etc., is a kind of high elasticity, high air tightness, medium resistance and weather resistance. pipe joints. This product takes advantage of the elasticity, high air tightness, medium resistance, weather resistance and radiation resistance of rubber. High temperature mold vulcanization. The Double Sphere Pipeline Expansion Joint is a rubber piece reinforced by fabric and a flat union. It is a kind of pipe joint with high elasticity, high air tightness, medium resistance and weather resistance.

Parameters of PVC Flange Double Sphere Pipeline Expansion Joint

Product model: KXT-F type
Nominal diameter: DN40-DN600mm
Inches: 1in to 24in
Product length: 155mm-330mm
Axial compression: 25mm-35mm
Axial stretch: 40mm-60mm
Lateral displacement: 40mm-35mm
Offset angle: 40 degrees – 30 degrees
Working pressure: 0.6Mpa, 1.0Mpa, 1.6Mpa
Product certification: ISO9001-2015
Inner and outer lining: NR, NBR, FKM, EPDM, PTFE，CR
Main frame: Nylon cord （Nylon 6）
Booster ring: multi-strand steel wire
Flange: pvc flange

Main purpose and scope of application

Can be widely used in water supply and drainage, circulating water, HVAC, fire protection, papermaking, pharmaceuticals, petrochemicals, ships, pumps, compressors, fans and other pipeline systems, using units such as power plants, water plants, steel mills, water utilities
Related PVC flange Double Sphere Pipeline Expansion Joint product recommendation
KXTPVC Double Sphere Pipeline Expansion Joint,
KST-FPVC flange double ball Pipeline Expansion Joint,
KYTPVC type concentric reducer rubber flexible joint,
KPT type PVC eccentric reducer rubber flexible joint,
WGD type PVC rubber elbow

Expand knowledge of PVC flange Double Sphere Pipeline Expansion Joint

PVC flange standard:
The formulation of the PVC flange standard refers to the national standard GB/T 10002.1-2006 “Rigid Polyvinyl Chloride (PVC-U) Pipe for Water Supply”, GB/T 10002.2-2003 “Rigid Polyvinyl Chloride (PVC-U) for Water Supply” Pipe Fittings”, while referring to Australia/New Zealand National Standard AS/N:S 4765:2000 “Modified Polyvinyl Chloride (PVC-M) for Pressure Piping”, South African Standard SANS 966-2:2006 “Pressure Piping System Standard No. 2″ Part: Modified Polyvinyl Chloride (PVC-M) Pressure Piping Systems”, British Standard BS PAS 27-1999 “Rigid Polyvinyl Chloride Alloy (PVC-A) Pipes and Elbows for Pressure Water Transmission”.
